Danfoss VLT FC 100 Design Guide

5.2.4 Ordering Numbers: High Power Kits
Kit Description Ordering Number Instruction Number
NEMA-3R (Rittal Enclosures) D3 Frame 176F4600 175R5922
D4 Frame 176F4601
E2 Frame 176F1852
NEMA-3R (Welded Enclosures) D3 Frame 176F0296 175R1068
D4 Frame 176F0295
E2 Frame 176F0298
Pedestal D Frames 176F1827 175R5642
Back Channel Duct Kit D3 1800mm 176F1824 175R5640
(Top & Bottom) D4 1800mm 176F1823
D3 2000mm 176F1826
D4 2000mm 176F1825
E2 2000mm 176F1850
E2 2200mm 176F0299
Back Channel Duct Kit D3/D4 Frames 176F1775 175R1107
(Top Only) E2 Frame 176F1776
IP00 Top & Bottom Covers D3/D4 Frames 176F1862 175R1106
(Welded Enclosures) E2 Frame 176F1861
IP00 Top & Bottom Covers D3 Frames 176F1781 177R0076
(Rittal Enclosures) D4 Frames 176F1782
E2 Frame 176F1783
IP00 Motor Cable Clamp D3 Frame 176F1774 175R1109
D4 Frame 176F1746
E2 Frame 176F1745
IP00 Terminal Cover D3/D4 Frame 176F1779 175R1108
Mains Shield D1/D2 Frames 176F0799 175R5923
E1 Frame 176F1851
Input Plates See Instr 175R5795
Loadshare D1/D3 Frame 176F8456 175R5637
D2/D4 Frame 176F8455
Top Entry Sub D or Shield Termination D3/D4/E2 Frames 176F1884 175R5964
IP00 to IP20 Kits D3/D4 Frames 176F1779
175R1108
E2 Frames 176F1884
USB Extension Kit D Frames 130B1155
177R0091 E Frames 130B1156
F Frames 176F1784
5.2.5 Ordering Numbers: Brake Resistors 10%
FC 301 - Mains: 200-240V (T2) - 10% Duty Cycle
FC 301 P
m (HO)
R
min
R
br, nom
R
rec
P
br avg
Order
no.
Perio
d
Cable cross
section
2
*
Therm. relay Max. brake
torque with
Rrec*
T2 [kW]
[Ω] [Ω] [Ω]
[kW] 175Uxxxx [s] [mm2] [A] [%]
PK25 0.25 368 408 425 0.095 1841 120 1.5 0.5 154 (160)
PK37 0.37 248 276 310 0.25 1842 120 1.5 0.9 142 (160)
PK55 0.55 166 185 210 0.285 1843 120 1.5 1.2 141 (160)
PK75 0.75 121 135 145 0.065 1820 120 1.5 0.7 149 (160)
P1K1 1.1 81 91.4 90 0.095 1821 120 1.5 1 160 (160)
P1K5 1.5 58.5 66.2 65 0.25 1822 120 1.5 2 160 (160)
P2K2 2.2 40.2 44.6 50 0.285 1823 120 1.5 2.4 143 (160)
P3K0 3 29.1 32.4 35 0.43 1824 120 1.5 2.5 148 (160)
P3K7 3.7 22.5 25.9 25 0.8 1825 120 1.5 5.7 160 (160)
How to Order FC 300 Design Guide
MG.33.BD.02 - VLT
®
is a registered Danfoss trademark 101
5 5
