Danfoss VLT FC 100 Design Guide

FC 302 - Mains: 200-240V (T2) - 10% Duty Cycle
FC 302 P
m (HO)
R
min
R
br, nom
R
rec
P
br avg
Order no. Period Cable cross
section
2
*
Therm.
relay
Max. brake
torque with
Rrec*
T2 [kW]
[Ω] [Ω] [Ω]
[kW] 175Uxxxx [s] [mm2] [A] [%]
PK25 0.25 382 467 425 0.095 1841 120 1.5 0.5 160 (160)
PK37 0.37 279 315 310 0.25 1842 120 1.5 0.9 160 (160)
PK55 0.55 189 211 210 0.285 1843 120 1.5 1.2 160 (160)
PK75 0.75 130 154 145 0.065 1820 120 1.5 0.7 160 (160)
P1K1 1.1 81 104 90 0.095 1821 120 1.5 1 160 (160)
P1K5 1.5 58.5 75.7 65 0.25 1822 120 1.5 2 160 (160)
P2K2 2.2 45 51 50 0.285 1823 120 1.5 2.4 160 (160)
P3K0 3 31.5 37 35 0.43 1824 120 1.5 2.5 160 (160)
P3K7 3.7 22.5 29.6 25 0.8 1825 120 1.5 5.7 160 (160)
FC 301/FC 302 - Mains: 200-240V (T2) - 10% Duty Cycle
AutomationDrive
FC 301/FC 302
P
m
(HO)
R
min
R
br. nom
R
rec
P
br avg
Order
no.
Period Cable
cross
section
2
*
Therm.
relay
Max. brake
torque with
R
rec
*
T2 [kW]
[Ω] [Ω] [Ω]
[kW] 175Uxxxx [s] [mm2] [A] [%]
P5K5 5.5 18 20 20 1 1826 120 1.5 7.1 158 (160)
P7K5 7.5 13 14 15 2 1827 120 1.5 11 153 (160)
P11K 11 9 10 10 2.8 1828 120 2.5 17 154 (160)
P15K 15 6 7 7 4 1829 120 4 24 150 (150)
P18K 18.5 5.1 6 6 4.8 1830 120 4 28 150 (150)
P22K 22 4.2 5 4.7 6 1954 300 10 36 150 (150)
P30K 30 3 3.7 3.3 8 1955 300 10 49 150 (150)
P37K 37 2.4 3 2.7 10 1956 300 16 61 150 (150)
How to Order FC 300 Design Guide
102 MG.33.BD.02 - VLT
®
is a registered Danfoss trademark
55
