IAHF 690V Typical Motor Used [kW]] Danfoss AHF 005 Danfoss AHF 010
Frequency converter size,
525-690 V
43 37 130B2328 130B2293 P37K
72 45 - 55 130B2330 130B2295 P45K - P55K
101 75 - 90 130B2331 130B2296 P75K - P90K
144 110 130B2333 130B2298 P110
180 132 130B2334 130B2299 P132
217 160 130B2335 130B2300 P160
288 200 - 250 130B2333 + 130B2333 130B2301 P200 - P250
324 315 130B2333 + 130B2334 130B2302 P315
365 355 130B2334 + 130B2334 130B2304 P355
397 400 130B2334 + 130B2335 130B2299 + 130B2300 P400
505 500 130B2300 + 130B2301 P500
576 560 130B2301 + 130B2301 P560
612 630 130B2301 + 130B2302 P630
730 710 130B2304 + 130B2304 P710
Matching the frequency converter and filter is pre-calculated based on 525V/690V and on a typical motor load (4 pole) and
160 % torque.
5.2.9
Ordering Numbers: Sine Wave Filter Modules, 200-500 VAC
3 x 240-500 V Frequency converter size
Rated filter
current at 50Hz
Min Switching
Freqency [kHz]
Max Output
Frequency ([Hz]
with Derating Danfoss IP20 Danfoss IP00 200-240V 380-440V 441-500V
2,5 5 120 130B2439 130B2404 PK25 - PK37 PK37 - PK75 PK37 - PK75
4,5 5 120 130B2441 130B2406 PK55 P1K1 - P1K5 P1K1 - P1K5
8 5 120 130B2443 130B2408 PK75 - P1K5 P2K2 - P3K0 P2K2 - P3K0
10 5 120 130B2444 130B2409 P4K0 P4K0
17 5 120 130B2446 130B2411 P2K2 - P4K0 P5K5 - P7K5 P5K5 - P7K5
24 4 100 130B2447 130B2412 P5K5 P11K P11K
38 4 100 130B2448 130B2413 P7K5 P15K - P18K P15K - P18K
48 4 100 130B2307 130B2281 P11K P22K P22K
62 3 100 130B2308 130B2282 P15K P30K P30K
75 3 100 130B2309 130B2283 P18K P37K P37K
115 3 100 130B2310 130B2284 P22K - P30K P45K - P55K P55K - P75K
180 3 100 130B2311 130B2285 P37K - P45K P75K - P90K P90K - P110
260 3 100 130B2312 130B2286 P110 - P132 P132
410 3 100 130B2313 130B2287 P160 - P200 P160 - P200
480 3 100 130B2314 130B2288 P250 P250
660 2 100 130B2315 130B2289 P315 - P355 P315 - P355
750 2 100 130B2316 130B2290 P400 P400 - P450
880 2 100 130B2317 130B2291 P450 - P500 P500 - P560
1200 2 100 130B2318 130B2292 P560 - P630 P630 - P710
1500 2 100 2X 130B2317 2X 130B2291 P710 - P800 P800
Matching the frequency converter and filter is pre-calculated based on 400V/480V and on a typical motor load (4 pole) and
160 % torque.
NOTE
When using Sine-wave filters, the switching frequency should comply with filter specifications in 14-01 Switching Frequency.
How to Order FC 300 Design Guide
MG.33.BD.02 - VLT
®
is a registered Danfoss trademark 115
