4.5 General Specifications
Mains supply:
Supply Terminals (6-Pulse) L1, L2, L3
Supply Terminals (12-Pulse) L1-1, L2-1, L3-1, L1-2, L2-2, L3-2
Supply voltage 200-240V ±10%
Supply voltage FC 301: 380-480V / FC 302: 380-500V ±10%
FC 302: 525-600V ±10%
Supply voltage FC 302: 525-690V ±10%
Mains voltage low / mains drop-out:
During low mains voltage or a mains drop-out, the FC continues until the intermediate circuit voltage drops below the minimum
stop level, which corresponds typically to 15% below the frequency converter's lowest rated supply voltage. Power-up and full
torque cannot be expected at mains voltage lower than 10% below the frequency converter's lowest rated supply voltage.
Supply frequency 50/60Hz ±5%
Max. imbalance temporary between mains phases 3.0 % of rated supply voltage
True Power Factor (λ) ≥ 0.9 nominal at rated load
Displacement Power Factor (cos ϕ) near unity (> 0.98)
Switching on input supply L1, L2, L3 (power-ups) ≤ 7.5kW maximum 2 times/min.
Switching on input supply L1, L2, L3 (power-ups) 11-75 kW maximum 1 time/min.
Switching on input supply L1, L2, L3 (power-ups) ≥ 90kW maximum 1 time/2 min.
Environment according to EN60664-1 overvoltage category III/pollution degree 2
The unit is suitable for use on a circuit capable of delivering not more than 100,000 RMS symmetrical Amperes, 240/500/600/
690V maximum.
Motor output (U, V, W):
Output voltage 0 - 100% of supply voltage
Output frequency (0.25-75kW) FC 301: 0.2 - 1000Hz / FC 302: 0 - 1000Hz
Output frequency (90-1000kW) 0 - 800
1)
Hz
Output frequency in Flux Mode (FC 302 only) 0 - 300Hz
Switching on output Unlimited
Ramp times 0.01 - 3600sec.
1)
Voltage and power dependent
Torque characteristics:
Starting torque (Constant torque) maximum 160% for 60 sec.
1)
Starting torque maximum 180% up to 0.5 sec.
1)
Overload torque (Constant torque) maximum 160% for 60 sec.
1)
Starting torque (Variable torque) maximum 110% for 60 sec.
1)
Overload torque (Variable torque) maximum 110% for 60 sec.
Pulse Pause
160%/1min 91.8%/10 min
150%/1min 93.5%/10 min
110%/1min 98.9%/10 min
Table 4.1 Overload capability
Pulse Pause
160%/60 s 0%/94 s
150%/60 s 0%/75 s
110%/60 s 0%/60 s
Table 4.2 Overload capability
Torque rise time in VVC+ (independent of fsw) 10 ms
Torque rise time in FLUX (for 5 kHz fsw) 1 ms
1) Percentage relates to the nominal torque.
2) The torque response time depends on application and load but as a general rule, the torque step from 0 to reference is 4-5 x
torque rise time.
Cable lengths and cross sections for control cables
1)
:
Max. motor cable length, screened FC 301: 50m/FC 301 (A1): 25m/ FC 302: 150m
Max. motor cable length, unscreened FC 301: 75m/FC 301 (A1): 50 m/ FC 302: 300m
Maximum cross section to control terminals, flexible/ rigid wire without cable end sleeves 1.5mm
2
/16 AWG
Maximum cross section to control terminals, flexible wire with cable end sleeves 1mm
2
/18 AWG
FC 300 Selection FC 300 Design Guide
MG.33.BD.02 - VLT
®
is a registered Danfoss trademark 85
4 4
