Mains Supply 6 x 525- 690VAC, 12-Pulse
FC 302 P900 P1M0 P1M2
High/ Normal Load* HO NO HO NO HO NO
Typical Shaft output at 550V [kW] 750 850 850 1000 1000 1100
Typical Shaft output at 575V [HP] 1050 1150 1150 1350 1350 1550
Typical Shaft output at 690V [kW] 900 1000 1000 1200 1200 1400
Enclosure IP21, 54 without/ with options
cabinet
F12/F13 F12/F13 F12/F13
Output current
Continuous
(at 550V) [A]
988 1108 1108 1317 1317 1479
Intermittent (60 sec overload)
(at 550V) [A]
1482 1219 1662 1449 1976 1627
Continuous
(at 575/ 690V) [A]
945 1060 1060 1260 1260 1415
Intermittent (60 sec overload)
(at 575/ 690V) [A]
1418 1166 1590 1386 1890 1557
Continuous KVA
(at 550V) [KVA]
941 1056 1056 1255 1255 1409
Continuous KVA
(at 575V) [KVA]
941 1056 1056 1255 1255 1409
Continuous KVA
(at 690V) [KVA]
1129 1267 1267 1506 1506 1691
Max. input current
Continuous
(at 550V ) [A]
962 1079 1079 1282 1282 1440
Continuous
(at 575V) [A]
920 1032 1032 1227 1227 1378
Continuous
(at 690V) [A]
920 1032 1032 1227 1227 1378
Max. cable size, motor [mm
2
(AWG
2)
)]
12x150
(12x300 mcm)
Max. cable size,mains F12 [mm
2
(AWG
2)
)]
8x240
(8x500 mcm)
Max. cable size,mains F13 [mm
2
(AWG
2)
)]
8x400
(8x900 mcm)
Max. cable size, brake [mm
2
(AWG
2)
)
6x185
(6x350 mcm)
Max. external mains fuses [A]
1
1600 2000 2500
Estimated power loss
at 600V [W]
4)
13755 15592 15107 18281 18181 20825
Estimated power loss
at 690V [W]
4)
14457 16375 15899 19207 19105 21857
F3/F4 Max added losses CB or Disconnect &
Contactor
556 665 634 863 861 1044
Max panel options losses 400
Weight,
enclosure IP21, IP 54 [kg]
1246/ 1541 1246/ 1541 1280/1575
Weight, Rectifier Module [kg] 136 136 136
Weight, Inverter Module [kg] 102 102 136
Efficiency
4)
0.98
Output frequency 0-500 Hz
Heatsink overtemp. trip 85 °C
Power card ambient trip 75 °C
* High overload = 160% torque during 60 sec., Normal overload = 110% torque during 60 sec.
1) For type of fuse see section Fuses.
2) American Wire Gauge.
3) Measured using 5 m screened motor cables at rated load and rated frequency.
4) The typical power loss is at nominal load conditions and expected to be within +/-15% (tolerence relates to
variety in voltage and cable conditions).
Values are based on a typical motor efficiency (eff2/eff3 border line). Motors with lower efficiency will also add to
the power loss in the frequency converter and opposite.
If the switching frequency is increased compared to the default setting, the power losses may rise significantly.
LCP and typical control card power consumptions are included. Further options and customer load may add up to
30W to the losses. (Though typical only 4W extra for a fully loaded control card, or options for slot A or slot B,
each).
Although measurements are made with state of the art equipment, some measurement inaccuracy must be
allowed for (+/-5%).
FC 300 Selection FC 300 Design Guide
84 MG.33.BD.02 - VLT
®
is a registered Danfoss trademark
44
