Danfoss VLT FC 100 Design Guide

Mains Supply 6 x 525- 690V AC, 12-Pulse
FC 302 P630 P710 P800
High/ Normal Load HO NO HO NO HO NO
Typical Shaft output at 550V [kW] 500 560 560 670 670 750
Typical Shaft output at 575V [HP] 650 750 750 950 950 1050
Typical Shaft output at 690V [kW] 630 710 710 800 800 900
Enclosure IP21, 54 without/ with options
cabinet
F10/F11 F10/F11 F10/F11
Output current
Continuous
(at 550V) [A]
659 763 763 889 889 988
Intermittent (60 sec overload)
(at 550V) [A]
989 839 1145 978 1334 1087
Continuous
(at 575/ 690V) [A]
630 730 730 850 850 945
Intermittent (60 sec overload)
(at 575/ 690V) [A]
945 803 1095 935 1275 1040
Continuous KVA
(at 550V) [KVA]
628 727 727 847 847 941
Continuous KVA
(at 575V) [KVA]
627 727 727 847 847 941
Continuous KVA
(at 690V) [KVA]
753 872 872 1016 1016 1129
Max. input current
Continuous
(at 550V ) [A]
642 743 743 866 866 962
Continuous
(at 575V) [A]
613 711 711 828 828 920
Continuous
(at 690V) [A]
613 711 711 828 828 920
Max. cable size, motor [mm
2
(AWG
2)
)]
8x150
(8x300 mcm)
Max. cable size,mains [mm
2
(AWG
2)
)]
6x120
(6x250 mcm)
Max. cable size, brake [mm
2
(AWG
2)
)
4x185
(4x350 mcm)
Max. external mains fuses [A]
1
900
Estimated power loss
at 600V [W]
4)
9201 10771 10416 12272 12260 13835
Estimated power loss
at 690V [W]
4)
9674 11315 10965 12903 12890 14533
F3/F4 Max added losses CB or Disconnect &
Contactor
342 427 419 532 519 615
Max panel options losses 400
Weight,
enclosure IP21, IP 54 [kg]
1004/ 1299 1004/ 1299 1004/ 1299
Weight, Rectifier Module [kg] 102 102 102
Weight, Inverter Module [kg] 102 102 136
Efficiency
4)
0.98
Output frequency 0-500Hz
Heatsink overtemp. trip 85 °C
Power card ambient trip 75 °C
* High overload = 160% torque during 60 s, Normal overload = 110% torque during 60 s
FC 300 Selection FC 300 Design Guide
MG.33.BD.02 - VLT
®
is a registered Danfoss trademark 83
4 4
