Danfoss VLT FC 100 Design Guide

Mechanical dimensions, frame size D
Frame size D1 D2 D3 D4
90 - 110kW
(380 - 500V)
37 - 132kW
(525-690V)
132 - 200kW
(380 - 500V)
160 - 315kW
(525-690V)
90 - 110kW
(380 - 500V)
37 - 132kW
(525-690V)
132 - 200kW
(380 - 500V)
160 - 315kW
(525-690V)
IP
NEMA
21
Type 1
54
Type 12
21
Type 1
54
Type 12
00
Chassis
00
Chassis
Shipping dimensions Height 650 mm 650 mm 650 mm 650 mm 650 mm 650 mm
Width 1730 mm 1730 mm 1730 mm 1730 mm 1220 mm 1490 mm
Depth 570 mm 570 mm 570 mm 570 mm 570 mm 570 mm
Drive dimensions Height 1209 mm 1209 mm 1589 mm 1589 mm 1046 mm 1327 mm
Width 420 mm 420 mm 420 mm 420 mm 408 mm 408 mm
Depth 380 mm 380 mm 380 mm 380 mm 375 mm 375 mm
Max
weight
104 kg 104 kg 151 kg 151 kg 91 kg 138 kg
Mechanical dimensions, frame sizes E and F
Frame size E1 E2 F1 F2 F3 F4
250 - 400kW
(380 - 500V)
355 - 560kW
(525-690V)
250 - 400kW
(380 - 500V)
355 - 560kW
(525-690V)
450 - 630kW
(380 - 500V)
630 - 800kW
(525-690V)
710 - 800kW
(380 - 500V)
900 - 1200kW
(525-690V)
450 - 630kW
(380 - 500V)
630 - 800kW
(525-690V)
710 - 800kW
(380 - 500V)
900 - 1200kW
(525-690V)
IP
NEMA
21, 54
Type 12
00
Chassis
21, 54
Type 12
21, 54
Type 12
21, 54
Type 12
21, 54
Type 12
Shipping
dimensions
Height
840 mm 831 mm 2324 mm 2324 mm 2324 mm 2324 mm
Width 2197 mm 1705 mm 1569 mm 1962 mm 2159 mm 2559 mm
Depth 736 mm 736 mm 1130 mm 1130 mm 1130 mm 1130 mm
Drive
dimensions
Height 2000 mm 1547 mm 2204 2204 2204 2204
Width 600 mm 585 mm 1400 1800 2000 2400
Depth 494 mm 498 mm 606 606 606 606
Max
weight
313 kg 277 kg 1004 1246 1299 1541
Mechanical Installation - ... FC 300 Design Guide
MG.33.BD.02 - VLT
®
is a registered Danfoss trademark 129
7 7
