To order drives with a different language package, please
contact your local sales office.
Ordering type codemodel number frame sizes A, B and C
Description Pos Possible choice
Product group 1-3 FC 30x
Drive series 4-6 301:FC 301
302: FC 302
Power rating 8-10 0.25-75 kW
Phases 11 Three phases (T)
Mains voltage 11-
12
T 2: 200-240V AC
T 4: 380-480V AC
T 5: 380-500V AC
T 6: 525-600V AC
T 7: 525-690V AC
Enclosure 13-
15
E20: IP20
E55: IP 55/NEMA Type 12
P20: IP20 (with back plate)
P21: IP21/ NEMA Type 1 (with back plate)
P55: IP55/ NEMA Type 12 (with back plate)
Z20: IP 20
1)
E66: IP 66
RFI filter 16-
17
H1: RFI filter class A1/B1
H2: No RFI filter, observes class A2
H3: RFI filter class A1/B1
1)
H6: RFI filter Maritime use
1)
HX: No filter (600V only)
Brake 18 B: Brake chopper included
X: No brake chopper included
T: Safe Stop No brake
1)
U: Safe stop brake chopper
1)
Display 19 G: Graphical Local Control Panel (LCP)
N: Numerical Local Control Panel (LCP)
X: No Local Control Panel
Coating PCB 20 C: Coated PCB
X. No coated PCB
Mains option 21 X: No mains option
1: Mains disconnect
3: Mains disconnect and Fuse
2)
5: Mains disconnect, Fuse and Load sharing
2,
3)
7: Fuse
2)
8: Mains disconnect and Load sharing
3)
A: Fuse and Load sharing
2, 3)
D: Load sharing
3)
Adaptation 22 X: Standard cable entries
O: European metric thread in cable entries
(A5, B1, B2, C1, C2 only)
Adaptation 23 X: No adaptation
Software release 24-
27
SXXX: Latest release - standard software
Software
language
28 X: Not used
1): FC 301/ frame sizeA1 only
2) US Market only
3): A and B frames have load-sharing built-in by default
Ordering type codemodel number frame sizes D and E
Description Pos Possible choice
Product group 1-3 301: FC 302
Drive series 4-6 302: FC 302
Power rating 8-10 37-560 kW
Phases 11 Three phases (T)
Mains voltage 11-
12
T 5: 380-500V AC
T 7: 525-690V AC
Enclosure 13-
15
E00: IP00/Chassis
C00: IP00/Chassis w/ stainless steel back
channel
E0D: IP00/Chassis, D3 P37K-P75K, T7
C0D: IP00/Chassis w/ stainless steel back
channel, D3 P37K-P75K, T7
E21: IP 21/ NEMA Type 1
E54: IP 54/ NEMA Type 12
E2D: IP 21/ NEMA Type 1, D1 P37K-P75K,
T7
E5D: IP 54/ NEMA Type 12, D1 P37K-P75K,
T7
E2M: IP 21/ NEMA Type 1 with mains
shield
E5M: IP 54/ NEMA Type 12 with mains
shield
RFI filter 16-
17
H2: RFI filter, class A2 (standard)
H4: RFI filter class A1
1)
H6: RFI filter Maritime use
2)
L2: Low Harmonic Drive with RFI filter,
class A2
L4: Low Harmonic Drive with RFI filter,
class A1
B2: 12-pulse drive with RFI filter, class A2
B4: 12-pulse drive with RFI filter, class A1
Brake 18 B: Brake IGBT mounted
X: No brake IGBT
R: Regeneration terminals (E frames only)
Display 19 G: Graphical Local Control Panel LCP
N: Numerical Local Control Panel (LCP)
X: No Local Control Panel (D frames IP00
and IP 21 only)
Coating PCB 20 C: Coated PCB
X. No coated PCB (D frames 380-480/500V
only)
Mains option 21 X: No mains option
3: Mains disconnect and Fuse
5: Mains disconnect, Fuse and Load
sharing
7: Fuse
A: Fuse and Load sharing
D: Load sharing
Adaptation 22 X: Standard cable entries
Adaptation 23 X: No adaptation
Software release 24-
27
Actual software
Software
language
28
1): Available for all D frames. E frames 380-480/500V only
2) Consult factory for applications requiring maritime certification
How to Order FC 300 Design Guide
96 MG.33.BD.02 - VLT
®
is a registered Danfoss trademark
55
