Danfoss VLT FC 100 Design Guide

Ordering type codemodel number, options (all frame sizes)
Description Pos Possible choice
A options 29-
30
AX: No A option
A0: MCA 101 Profibus DP V1 (standard)
A4: MCA 104 DeviceNet (standard)
A6: MCA 105 CANOpen (standard)
AN: MCA 121 Ethernet IP
AL: MCA-120 ProfiNet
AQ: MCA-122 Modbus TCP
AT: MCA 113 Profibus converter VLT3000
AU: MCA-114 Profibus Converter VLT5000
B options 31-
32
BX: No option
BK: MCB 101 General purpose I/O option
BR: MCB 102 Encoder option
BU: MCB 103 Resolver option
BP: MCB 105 Relay option
BZ: MCB 108 Safety PLC Interface
B2: MCB 112 PTC Thermistor Card
B4: MCB-114 VLT Sensor Input
C0/ E0 options 33-
34
CX: No option
C4: MCO 305, Programmable Motion
Controller
BK: MCB 101 General purpose I/O in E0
BZ: MCB 108 Safety PLC Interface in E0
C1 options/ A/B
in C Option
Adaptor
35 X: No option
R: MCB 113 Ext. Relay Card
Z: MCA 140 Modbus RTU OEM option
E: MCF 106 A/B in C Option Adaptor
C option
software/ E1
options
36-
37
XX: Standard controller
10: MCO 350 Synchronizing control
11: MCO 351 Positioning control
12: MCO 352 Center winder
AN: MCA 121 Ethernet IP in E1
BK:MCB 101 General purpose I/O in E1
BZ: MCB 108 Safety PLC Interface in E1
D options 38-
39
DX: No option
D0: MCB 107 Ext. 24V DC back-up
