Danfoss vlt FC 102 Instruction Manual

Type Designation P11K1 P15K P18K P22K P30K P37K P45K P55K P75K P90K Typical Shaft Output [kW] 11 15 18.5 22 30 37 45 55 75 90
IP20/Chassis B3 B3 B3 B4 B4 B4 C3 C3 C4 C4 IP21/NEMA 1 B1 B1 B1 B2 B2 C1 C1 C1 C2 C2 IP55/Type 12 B1 B1 B1 B2 B2 C1 C1 C1 C2 C2 IP66/NEMA 4X B1 B1 B1 B2 B2 C1 C1 C1 C2 C2 Output current Continuous (3 x 525–550 V) [A] 19 23 28 36 43 54 65 87 105 137
Intermittent (3 x 525–550 V) [A] 21 25 31 40 47 59 72 96 116 151 Continuous (3x525–600 V) [A] 18 22 27 34 41 52 62 83 100 131 Intermittent (3x525–600 V) [A] 20 24 30 37 45 57 68 91 110 144 Continuous kVA (525 V AC) [kVA]
18.1 21.9 26.7 34.3 41 51.4 61.9 82.9 100 130.5
Continuous kVA (575 V AC) [kVA]
17.9 21.9 26.9 33.9 40.8 51.8 61.7 82.7 99.6 130.5
Max. input current Continuous (3x525–600 V) [A] 17.2 20.9 25.4 32.7 39 49 59 78.9 95.3 124.3 Intermittent (3x525–600 V) [A] 19 23 28 36 43 54 65 87 105 137 Additional specifications Estimated power loss at rated max. load [W]
4)
300 400 475 525 700 750 850 1100 1400 1500
IP21, IP55, IP66 max. cable
cross-section (line power, brake and load sharing) [mm
2
/(AWG)]
16, 10, 10 (6, 8, 8) 35,-,-(2,-,-) 50,-,- (1,-,-) 95 (4/0)
IP21, IP55, IP66 max. cable cross-section (motor) [mm
2
/
(AWG)]
10, 10, - (8, 8, -) 35, 25, 25 (2, 4, 4) 50,-,- (1,-,-) 150 (300 MCM)
IP20 max. cable cross-section (line power, brake and load sharing) [mm
2
/(AWG)]
10, 10, - (8, 8, -) 35, -, - (2, -, -) 50,-,- (1,-,-) 150 (300 MCM)
Max. cable cross-section with disconnect
16, 10, 10 (6, 8, 8) 50, 35, 35 (1, 2, 2)
95, 70, 70
(3/0, 2/0,
2/0)
185, 150, 120 (350 MCM, 300 MCM,
4/0)
Line power disconnect switch
included:
16/6 35/2 70/3/0 185/kcmil350
Efficiency
3)
0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98 0.98
Table 8.7 Line Power Supply 3x525–600 V AC - Normal overload 110% for 1 minute, P11K-P90K
Specifications
VLT
®
HVAC Drive Instruction Manual
58 MG11AJ22 - Rev. 2013-09-13
88
