8.1.3 Line Power Supply 3x525–600 V AC
Type Designation P1K1 P1K5 P2K2 P3K0 P3K7 P4K0 P5K5 P7K5
Typical Shaft Output [kW] 1.1 1.5 2.2 3.0 3.7 4.0 5.5 7.5
IP20/Chassis A3 A3 A3 A3 A2 A3 A3 A3
IP21/NEMA 1 A3 A3 A3 A3 A2 A3 A3 A3
IP55/Type 12 A5 A5 A5 A5 A5 A5 A5 A5
IP66/NEMA 4X A5 A5 A5 A5 A5 A5 A5 A5
Output current
Continuous (3 x 525–550 V) [A] 2.6 2.9 4.1 5.2 - 6.4 9.5 11.5
Intermittent (3 x 525–550 V) [A] 2.9 3.2 4.5 5.7 - 7.0 10.5 12.7
Continuous (3x525–600 V) [A] 2.4 2.7 3.9 4.9 - 6.1 9.0 11.0
Intermittent (3x525–600 V) [A] 2.6 3.0 4.3 5.4 - 6.7 9.9 12.1
Continuous kVA (525 V AC) [kVA] 2.5 2.8 3.9 5.0 - 6.1 9.0 11.0
Continuous kVA (575 V AC) [kVA] 2.4 2.7 3.9 4.9 - 6.1 9.0 11.0
Max. input current
Continuous (3x525–600 V) [A] 2.4 2.7 4.1 5.2 - 5.8 8.6 10.4
Intermittent (3x525–600 V) [A] 2.7 3.0 4.5 5.7 - 6.4 9.5 11.5
Additional specifications
Estimated power loss
at rated max. load [W]
4)
50 65 92 122 - 145 195 261
IP20 max. cable cross-section
5)
(line
power, motor, brake and load
sharing) [mm
2
/(AWG)]
4, 4, 4 (12, 12, 12)
(min. 0.2 (24))
IP55, IP 66 max. cable cross-section
5)
(line power, motor, brake and load
sharing) [mm
2
/(AWG)]
4, 4, 4 (12, 12, 12)
(min. 0.2 (24))
Max. cable cross-section with
disconnect
6, 4, 4 (12, 12, 12)
Line power disconnect switch
included:
4/12
Efficiency
3)
0.97 0.97 0.97 0.97 - 0.97 0.97 0.97
Table 8.6 Line Power Supply 3x525–600 V AC - Normal overload 110% for 1 minute, P1K1-P7K5
Specifications
VLT
®
HVAC Drive Instruction Manual
MG11AJ22 - Rev. 2013-09-13 57
8 8
