Tally Dascom 5130P
37
4.6.4 I/F Emulation
Parameter
group
Parameter Possible
settings
Description
Interface Parallel
Serial*(Menu2)
USB*(Menu1)
Selects the interface. Printer can be configured either for
serial, parallel or USB connection. Two interfaces can be used
at the same time, one assigned to USER1 and one to USER2.
If Serial is selected
Baud Rate 1200
2400
4800
9600 *
19200
38400
Selects the data transmission rate (baud rate) (baud=bit per
second).
Data
Length
7
8 *
Selects the number of data bits per data byte.
Parity None *
Odd
Even
The parity test for received data bytes can be selected. None
causes transmission in both directions without parity bit. If
Even or Odd is selected, the bytes are checked to ensure they
have even or odd parity.
Stop bit 1 *
2
Selects if one or two stop bits are used per data byte.
Protocol READY/BUSY *
Xon/Xoff
Selects the type of protocol, i.e. a certain set of rules and
procedures for ensuring error-free data exchanges between
computer and printer.
CTS Invalid * Sets the signal CTS (Clear To Send) off. CTS is reserved for
future enhancements.
If Parallel is selected
I-PRIME Yes *
No
Selects receiving initial signal mode, if set to Yes, the printer
resets when receiving initial signal, if No, the printer does not
reset when receiving initial signal.
Interface
Setup
CX-BiD Yes *
No
Sets the bidirectional data transfer (IEEE 1284): if set to Yes,
ECP is supported, if No, only Nibble mode is supported.
