7.2.3 USB interface
USB interface pin assignment
Pin Signal name Description
1 VBUS +5V power supply
2 D- data
3 D+ data
4 S.GND ground
USB interface connector diagram
Note:
1. Use a standard USB interface cable to connect the printer and the computer.
2. Normally PR2-Olivetti emulation does not support USB printing mode. Please use serial interface to
print.
