Tally Dascom 5130P
53
Noise Level Less than 55 dB(A) in 10CPI draft ASCII (Conforming to ISO7779 standard)
Ambient
Conditions
Temperature Operating: +5 to +40 °C.
Storage: -20 to +60 °C
Relative humidity Operating: 10 to 90%RH
(No condensation)
Storage: 5 to 95%RH
(No condensation)
Dimensions 384 mm (W) x 313 mm (D) x 203 mm (H)
Weight 9 kg
Power Supply
Power cord: Detachable
Voltage rating: AC 230V(180V~264V) / 50Hz to60Hz
AC 110V/120V, 60Hz (factory option)
Stand by: Less than 3.87W
ESD: Comply with IEC801-2
Contact discharge: 4kV
Air discharge: 8kV
Power
consumption
32 W (Test pattern is specified in standard ISO/IEC 10561.)
MTTR Less than 20 minutes
MTBF 10,000 P.O.H (At 25% duty cycle. The print head is excluded.)
Certification CCC, CB, CE, UL, FCC, ES, ISTA, RoHS, WEEE, REACH, ChemVerbotsV
Remarks:
(1) CPI=Characters per Inch
(2) CPS=Characters per Second
(3) 1 Inch=25.4 mm
(4) DPI=Dots per Inch
(5) CPL=Characters per Line
