Chapter 15. Technical Specifications
15.1. Environmental Conditions
Operating Temperature: 0 to 50 degrees Celsius
Storage Temperature: -20 to 65 degrees Celsius
Humidity: 10 to 90% non condensing
15.2. Power Suply and Consumption
DC: 36 to 72 V for all dispositives
15.2.1. Power
Interface Board: 21A
MPU: 3A
Multipurpose: 3A
FAN Board: 3A
Fastons: 20A each, total 40A
15.3. Dimensions
Height 240 mm (DM4004), 400mm (DM4008) and 44mm (DM4001)
Width 440mm without L brackets to install in 19” rack
483mm with L brackets to install in 19 ” rack
Depth 280 mm (DM4004, DM4008 and DM4001)
