DS2100N REFERENCE MANUAL
94
7
DS2100N-1204 High Performance (Standard Resolution)
2
1
0
1
5
4
3
2
3
4
5
(in)
0 1 3 2 106
(in)
45 7 89
0 20 40 60 80 100 120 140 160 180 200 220 240 260
(mm)
120
100
80
60
40
20
0
20
40
60
80
100
120
(mm)
280
11
300
12
0.15 mm
(6 mils)
0.20 mm
(8 mils)
0.30 mm
(12 mils)

0.50 mm
(20 mils)
NOTE: (0,0) is the center of the laser beam output window.
CONDITIONS
Optic Version = Linear
Code = Interleaved 2/5 or Code 39
PCS = 0.90
"Pitch" angle =
0
"Skew" angle =
15
"Tilt" angle =
0
*Code Resolution = High for 0.30 mm, (12 mils) codes and smaller
Standard for 0.50 mm (20 mils) codes and greater
*Reading Conditions = Standard
*Scan Speed = 1000 scans/sec
* Parameter selectable in Genius™
