Datalogic DS2100N - DS2100 N-2204 Reading Diagrams

READING FEATURES
95
7
DS2100N-2204 High Performance (High Resolution)
1
0
2
1
2
(in)
0 1 5 3
(in)
24
0
10
20
30
40
50 60
70 80
90
100
110
120
130
(mm)
60
50
40
30
20
10
0
10
20
30
40
50
60
(mm)
0.12 mm
(5 mils)
0.15 mm
(6 mils)

0.20 mm
(
8 mils
)
NOTE: (0,0) is the center of the laser beam output window.
CONDITIONS
Optic Version = Linear
Code = Interleaved 2/5 or Code 39
PCS = 0.90
"Pitch" angle =
0
"Skew" angle =
15
"Tilt" angle =
0
*Code Resolution = High for 0.15 mm, (6 mils) codes and smaller
Standard for 0.20 mm (8 mils) codes
*Reading Conditions = Standard
*Scan Speed = 1000 scans/sec
* Parameter selectable in Genius™
