Symbologies
124
Magellan
TM
3300HSi
Interleaved 2 of 5 — continued
Interleaved 2 of 5 Length 1, Length 2 Programming Instructions
1. Scan the START bar code.
2. Scan either the Set Length 1 or Set Length 2 bar code.
3. Turn to
Appendix C, Alpha-Numeric Pad and scan the two digits (zero padded) representing
the length in decimal notation
.
4. Scan the END bar code.
NOTE
For Interleaved 2 of 5 bar codes, lengths must
be an even number. Additionally, all check and
data characters are included in the length calcu-
lations.
START / END
PROGRAMMING bar codes
DEFAULT SETTING FOR THIS FEATURE: 06
Set Length 1
Set Length 2
DEFAULT SETTING FOR THIS FEATURE: 50
To Next Page
