Datalogic Magellan 3300HSi Product Guide

microSD Function Details
Product Reference Guide 187
Export a Configuration file from the Scanner to the micro SD card
By Autorun.dls file
1. Generate a text file by any text editor as follows and save it as autorun.dls
$START$
DUMPCFG,SDCONFIG.tex
$END$
2. Save or copy file autorun.dls to microSD card
3. Insert the microSD card to scanner
4. Wait for 3 seconds,
A scanner configuration file named SDCONFIG.txt is saved to the micro SD card.
Export Scanner Status to microSD card
The data includes scanner ID, statistics and scanner health.
By scanning a label
1. Insert the micro SD card into the scanner
2. Scan the status export label
<FNC3>STATUS<CR>
3. Upon scanner audio indication of completion, the scanner status text file named status.txt is saved to the
micro SD card.

Datalogic Magellan 3300HSi Specifications

General

Scanner type	1D
Decoding standards	GS1, MicroPDF417, PDF417
Optical sensor resolution	1280 pixels
Light levels (direct sunlight)	0 - 86100 lx
Dimensions (WxDxH)	152 x 87 x 152 mm
Power consumption (active)	9.9 W
Standard interfaces	USB, RS-232
Input voltage	90 - 264 V
Power requirements	47 - 63 Hz
Power consumption (standby)	2 W
Certification	RoHS, EN 60825-1, IEC 60825, IEC 60825-1
Product color	Stainless steel
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Weight	790 g
