Datalogic Magellan 3300HSi Product Guide

Getting Started
6 Magellan
TM
3300HSi
LED and Beeper Indicators
The scanner’s beeper sounds and its green LED illuminates to indicate various functions
or errors on the scanner. The tables below list these indications. One exception to the
behaviors listed in the tables is that the scanner’s functions are programmable, and may
or may not be turned on. For example, certain indications, such as the power-up beep
can be disabled using programming bar code labels.
Table 1. Green LED Indications
LED
INDICATION
INDICATION COMMENT
Power-on
indication
Bright green flash Indicates the scanner has finished all its power up tests and is now
ready for operation.
Good Read
Indication
Bright green flash Indicates a bar code has been read and decoded.
Scanner Ready Constant dim green The scanner is ready for operation. The LED is also configurable to
off when idle and ready for operation
Sleep Mode Green LED slowly and continuously
changes from off to dim to off.
The scanner is in Sleep Mode. To wake the scanner up, move an
object in front of its window or press the button located just beneath
the removable top cover of the unit. This indication is optionally con-
figurable and may have been programmed to behave differently.
Host Disable Constant green flash at 1 Hz (100mS
on, 900mS off)
The scanner is disabled due to receiving a disable command from
the POS terminal.
Diagnostics Varies (see
Error Codes on page 4
for more information)
The LED can provide diagnostic feedback if the scanner discovers a
problem during SelfTest.
Prog. Mode See
Host Disable above. The scanner is in Programming Mode.

Datalogic Magellan 3300HSi Specifications

General

Scanner type	1D
Decoding standards	GS1, MicroPDF417, PDF417
Optical sensor resolution	1280 pixels
Light levels (direct sunlight)	0 - 86100 lx
Dimensions (WxDxH)	152 x 87 x 152 mm
Power consumption (active)	9.9 W
Standard interfaces	USB, RS-232
Input voltage	90 - 264 V
Power requirements	47 - 63 Hz
Power consumption (standby)	2 W
Certification	RoHS, EN 60825-1, IEC 60825, IEC 60825-1
Product color	Stainless steel
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Weight	790 g
