Datalogic Magellan 3300HSi Product Guide

Getting Started
4 Magellan
TM
3300HSi
Error Codes
If an error is detected, the scanner will sound a long low tone (for three seconds) and flash its
LED, indicating a failure. When this occurs, remove the top cover and press the Scanner Push
Button to hear the error code. If it is configured to do so, the scanner will sound a series of beeps
corresponding to the error code and/or flash its LED simultaneous to the beeps. The table
below describes what these codes mean and what action should be taken for each.
Installation
For comfortable slide-through scanning, mount the scanner level with the countertop. Follow
these steps for flush installation:
1. Decide the best situation for the scanner by considering...
• Proximity to the user. Verify that checkstand features allow the scanner to be within
easy reach of the user, without interfering with cash drawers or other equipment.
• Cable routing to and from the scanner: Can cables and connected devices be routed in
such a way as to be protected from damage or tampering?
• Mounting stability. Avoid placing the scanner in such a way as to subject it to excess
vibration, bumping, spillage, etc.
• Peripheral connections from the scanner, such as a handheld device.
2. The countertop must be modified to accept the scanner. At the time of this writing, three
options are available.
•
Figure 3a shows the dimensions for the opening and other details if a shelf is to be built
to support the unit.
•
Figure 3b details the cutout dimensions if an adapter fixture holding the scanner will
rest with its rim above the countertop.
•
Figure 3c provides dimensions if an adapter fixture holding the scanner will be recessed
to be flush with the countertop.
3. Remove the Connector Cover, then connect and route the cables at the scanner.
4. Seat the scanner or in the countertop opening (or adapter).
NUMBER OF
LED FLASHES/
BEEPS
ERROR CORRECTIVE ACTION
1
Configuration
Contact Helpdesk for assistance
2
Interface PCB
6
Main PCB
10
Button Error
12
Imager Module
13
Software ID Failure
14
Software Fatal Fault

Datalogic Magellan 3300HSi Specifications

General

Scanner type	1D
Decoding standards	GS1, MicroPDF417, PDF417
Optical sensor resolution	1280 pixels
Light levels (direct sunlight)	0 - 86100 lx
Dimensions (WxDxH)	152 x 87 x 152 mm
Power consumption (active)	9.9 W
Standard interfaces	USB, RS-232
Input voltage	90 - 264 V
Power requirements	47 - 63 Hz
Power consumption (standby)	2 W
Certification	RoHS, EN 60825-1, IEC 60825, IEC 60825-1
Product color	Stainless steel
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Weight	790 g
