Datalogic Magellan 3300HSi

Product Reference Guide 11
Code 128 Supplemental
• Supplemental data is appended to any EAN base label.
•Prefix must be ASCII characters ']C0'.
• length of Supplemental data including prefix is variable but must be at least 9.
• Examples: addon portion is highlighted data is underlined.
Bookland
• The 'Bookland' / ISBN code will be formatted as a vendor specific AIM label.
• Prefix must be ASCII characters ']X0'.
• length of label data including prefix is 13.
• Examples: ']X01234567890'.
Code 39
• Check character must be included in label data.
• Label length including start, stop and check characters and excluding prefix characters must meet require-
ments imposed by the main scanner's fixed or variable label length control for this symbology type.
• Start and stop characters "*" must be included in label.
• Prefix must be ASCII characters ']A0' or ']A1'.
• Example: '*]A0Code 39.TEST*'.
Codabar
• Check character must be included in label data.
• Label length including check character and excluding prefix characters must meet requirements imposed by
the main scanner's fixed or variable label length control for this symbology type.
• Prefix must be ASCII characters ']F0'.
• Start stop character sets must meet the matching requirement set forth by the scanner configuration item
Codabar Start Stop Character Match.
• Start stop character sets s must be of the form ABCD/ABCD and must be included in the label.
• Example: ']F0s$99.95s' (the lower case ‘s’ at each end of the example is a placeholder for the start stop charac-
ter set).
UPC-A Code 128 addon
']E00060992011187]C0
81000009
51'
UPC-E Code 128 addon
'E00000000998875]C0
810000095
1'
EAN-8 Code 128 addon
']E400210126]C0
8100000951'
EAN-13 Code 128 addon
']E01101234567891]C0
81000009
51'
