1-4 Magellan
®
9500
Scanner and Scanner/Scale Nomenclature
Controls, indicators and other nomenclature are shown in Figure 1-1.
Figure 1-1. Scanner/Scale Nomenclature
Produce Rail
All Weighs™ Platter
Scanner LED (Green)
Scale LED (Yellow)
Wei
g
hin
g
Surface — Lean
O
versize Produce Her
e
V
e
rti
ca
l Win
d
o
w
Horizont
a
l Win
d
o
w
Scale Zero
Push Button
Manual EAS
Deactivation Push
Button
Bonnet
Volume
/
Tone Push Butto
n
EAS LED
(Tri-Color)
