Datalogic Magellan 9500

Power Cable
Product Reference Guide B-7
Power Cable
Connector Hardware
6 pin Molex
Cable Pinout
Table B-6Power Cable Pinouts
PIN # FUNCTION DESCRIPTION
1 EARTH GND Earth Ground
2 SIGNAL GND Signal Ground
3 +5V IN +5V in
4 N/C No Connection
5 N/C No Connection
6 +12V IN +12V in
