Datalogic Magellan 9500

B-4 Magellan
®
9500
IBM Cable Pinout
Scanner and Scale
Connector Hardware
RJ45, 10 Position
Cable Pinout
Table B-3IBM Cable Pinouts
PIN # FUNCTION DESCRIPTION
1 N/C No Connection
2 N/C No Connection
3 N/C No Connection
4 LINEB Line B
5 N/C No Connection
6 LINEA Line A
7 N/C No Connection
8 +5V out +5V out
9 GND Signal Ground
10 N/C No Connection
