6-190 Magellan
®
9500
RSS Expanded Fixed Length 2
This feature specifies RSS Expanded second fixed length.
To set this feature:
1. Scan the SWITCH bar code.
2. Scan the bar code,
SET RSS EXPANDED FIXED LENGTH 2 below.
You’ll need to cover any unused bar codes on this and the facing
page to ensure that the scanner reads only the bar code you intend
to scan.
3. Scan the appropriate digits from the keypad in Appendix C that rep-
resent the desired fixed label length. The selectable range for this
option is 00 to 74. Pad all single digit numbers with a leading zero
to yield a two-digit entry (00-74).
4. Complete the programming sequence by scanning the SWITCH
bar code.
SET RSS EXPANDED FIXED LENGTH 2
NOTE
This applies when RSS Expanded Length Control is set to fixed-length
decoding.
If Fixed Length 2 is set to 00 (zero), then Fixed Length 1 will apply.
