EAS Comm Port
Product Reference Guide B-9
EAS Comm Port
EAS Deactivator Control Box Connection
Connector Hardware
RJ10
Cable Pinout
Table B-8EAS Comm Port Cable Pinouts
PIN # FUNCTION DESCRIPTION
1 VCC5 VCC5
2 EAS DEACT EN~ EAS Deactivation
3 VCC5 VCC5
4 EAS DETECT EN~ EAS Detection
5 EAS LBL DETECT EN~ EAS tag Detect
6 GND Signal Ground
7 N/C No Connection
8 EAS TXD EAS Transmit Data
9 EAS RXD EAS Receive Data
10 GND Signal Ground
