MEMOR™ 30/35 FAMILY
DATA CAPTURE
Embedding new Datalogic Halogen™ DE2121-DL and DE2121-ER scan engines, the
Memor 30/35 family delivers impressive versatility for any application in an extended
range of working distances from 5cm/1.97in up to 10m /32.8ft.
DeepSight™ integrated technology provides superior sensitivity and high visible illumi-
nation system, guaranteeing first-class reading performances even in extreme light and
dark environment conditions. Its outstanding motion tolerance allows to decode poorly
printed barcodes as well as barcodes displayed on mobile devices and LCD screens.
See "
Scanner & Decoder" on page 29 for instructions on configuring the scanner settings.
Models with DE2121-DL
To scan a bar code symbol:
1. Point the scan window at the barcode from a distance within the reading range.
2. Press one of the scan triggers. The imager projects a red laser aiming cross that is
used to position the barcode or object within the field of view.
3. Center the symbol in any orientation within the aiming pattern. Ensure the entire
symbol is within the rectangular area formed by the brackets in the aiming pat-
tern, then either wait for the timeout or release the scan trigger to capture the
image. A red beam illuminates the symbol, which is captured and decoded.
If the scan has been successful:
• If enabled, the good read beep plays.
• If enabled, the GreenSpot projects a green spot onto the bar code image.
• If enabled, the good read indicator glows solid green.
Linear Bar Code
2D Matrix Symbol
