Menu Commands
Product Reference Guide 10-9
Word Length:
Data Bits, Stop
Bits, and Parity
7 Data, 1 Stop, Parity Even
232WRD3
2-9
7 Data, 1 Stop, Parity None
232WRD0
2-9
7 Data, 1 Stop, Parity Odd
232WRD6
2-9
7 Data, 2 Stop, Parity Even
232WRD4
2-9
7 Data, 2 Stop, Parity None
232WRD1
2-9
7 Data, 2 Stop, Parity Odd
232WRD7
2-9
8 Data, 1 Stop, Parity Even
232WRD5
2-9
*8 Data, 1 Stop, Parity None
232WRD2
2-9
8 Data, 1 Stop, Parity Odd
232WRD8
2-9
RS-232 Receiver
Time-out
Range 0 - 300 seconds
232LPT###
2-10
RS-232 Hand-
shaking
*RTS/CTS Off
232CTS0
2-11
RTS/CTS On
232CTS1
2-11
*XON/XOFF Off
232XON0
2-11
XON/XOFF On
232XON1
2-11
*ACK/NAK Off
232ACK0
2-11
ACK/NAK On
232ACK1
2-11
Output Selections
Image VGA
*Off BEPBEP0 3-1
On BEPBEP1 3-1
Beeper - Good
Read
Off BEPBEP0
3-2
*On BEPBEP1 3-1
Beeper Volume -
Good Read
Off BEPLVL0
3-1
Low BEPLVL1 3-2
*Medium BEPLVL2 3-2
High BEPLVL3 3-2
Beeper Pitch -
Good Read (Fre-
quency)
Low (1250Hz) BEPFQ11250 3-2
Medium (2300hz) BEPFQ12300 3-2
*High (2900Hz) BEPFQ12900 3-2
Beeper Duration -
Good Read
*Normal Beep BEPBIP0
3-3
Short Beep BEPBIP1 3-3
Selection
Setting
* Indicates default
Serial
Command
# Indicates a
numeric entry
Page
