[C Header] [Scanner_Addr] [Scanner_Addr delimiter] [Cradle_Addr] [Cradle_Addr_ delimiter] [Time
Stamp ][Time Stamp Delimiter]
[ S Header]
[Code ID] [Code len] CODE
[S Terminator]
[C Terminator ]
16-Key DK Message Formatting
Product Reference Guide
83
Code ID, Code Length and Code can be different content in the 16-key DK
model. These features can be programmed with Scanner Data Header/Ter-
minator on page 65, or Keypad Data Header/Terminator on page 69.
Field code ID and Code length may also be programmed in
the DK model:
[C Header] [Scanner Addr] [Scanner Addr delimiter] [Cradle_Addr] [Cradle Addr delimiter] [Time Stamp
][Time Stamp Delimiter]
[ S Header]
[Code ID] [C len] CODE
[S Term]
[C Term ]
[C Header] [Scanner Addr] [Scanner Addr delimiter] [Cr
adle Addr] [Cradle Addr delimiter] [Time Stamp]
[Time Stamp Delimiter]
[ S Header]
[S ID] [S len] CODE
[S Term]
[C Term]
The prefix C means programmed from general Data Format beginning on
page 39, and the prefix S means it is progr
ammed from Scanner Code ID and
Scanner Code Length in Display and Keypad for 16-keys, on page 53.
NOTE: in case of double formatting for [Code ID] [Ccode len], only one of
these is included in message formatting. Specific Data Format
[S ID] [S len]
takes priority over general Data Format.
The code field [CODE] as addi
tional formatting in the 16-key model, when
the device is programmed in Qty/Code mode.
