Compatibility with PM8300
10
PowerScan™ PD9330/PBT9300/PM9300
BC-8060 STAR-SYSTEM™ NETWORK SETUP
When the BC-8060 cradle model is used in an RS-485 network, it must be
initially configured. To do this using configuration barcodes, follow the pro-
cedure below using any PowerScan™ M8300 reader.
1. Set BC-8060 Address
+
four digits for the BC-8060 Address (from 00
00 to 1999).
All cradles used in the network must have
different addresses.
2. Exit and Save configuration.
3. Read the Bind code to pair the PowerScan™ M8300 to the BC-8060
cradle for configuration.
Bind
The green LED on the PowerScan™ M8300 will blink; the reader is ready to
be inserted into the cradle.
4. Firmly insert the reader into the BC-8060 cradle within 10 seconds,
a beep will be emitted, signaling that the BC-8060 cradle has been
paired to the PowerScan™ M8300, and the green LED on the reader
will go off.
