ELECTRICAL CONNECTI
O
NS
7
3
3.1.3
VSM Monitor
3
1
2
4
3
1
2
4
M12 4-Pin Male
(Power supply)
pin
1
:
+24 Vdc
pin 2:
Reserved
pin
3
:
GROUND
pin 4:
Reserved
M12 Reverse Keyed 4-Pin Male
(Ethernet connection)
pin
1
: Ethernet RX+
pin
2
: Ethernet TX+
pin
3
: Ethernet RX-
pin
4
: Ethernet TX-
3.2
POINT-
TO
-POINT CONNECTION
Connect DataVS2 to VSM using the s
pecific connection cable (Da
taVS-
CV
-VSM-
xx).
3.3
LAN CONNECTION
Connect
DataVS2
and
VSM to
LAN
using
the
specific
connection
cable
(DataVS
-
CV
-RJ45D
-
03).
Power
DATAVS-
CV
-VSM-
xx
Power
LAN
Power
Power
DATAVS-
CV
-RJ45D-
03
Power
Power
12
14
