DATAVS2-VSM INSTRUCTION MANUAL
22
7
7.5 TRIGGER MODE CHANGE
Select "Trigger" and press SET to access the management screen of the trigger mode.
As you can see in the image, the VSM is split into two main areas: the parameters that the
user can change are displayed on the right side of the monitor, while the remaining area
displays the image acquired by the sensor.
At the bottom of the monitor also is shown the name of the selected trigger parameter;
Parameters that can be modified are “Trigger Mode” and “Trigger Delay”.
The user can scroll through the parameter using the UP/DOWN ARROWS.
To change the current value, use the UP/DOWN ARROW. Each time the button is pressed,
the value associated to the slider, is increased or decreased of one unit (to change the value
faster keep the corresponding button pressed).
