DATAVS2-VSM INSTRUCTION MANUAL
7 INSPECTION PARAMETER CHANGE
7.1 CURRENT INSPECTION CHANGE
To change the sensor parameters, press TEACH in the monitor mode. The following panel is
displayed:
At this point the user can choose to change the current inspection or modify the parameters.
Selecting “Adjust Current Inspection” the user accesses the main panel of the Adjust
status:
As you can see in the image, the VSM is split into two main areas: the field range of the
camera and the configuration options available.
The image acquired by the sensor is displayed in the first area. The configuration options are
displayed on the right side of the monitor, where the user can scroll through the options using
the UP/DOWN ARROWS.
