FIRST APPROACH TO VSM
9
4
4 FIRST APPROACH TO VSM
4.1 INTRODUCTION
The configuration of the DataVS2 vision sensor has to be made only through DataVS2 GUI.
To simplify the instructions described in this manual, the pressing of the buttons on the VSM
user interface will be indicated as follows:
4.2 VSM USER INTERFACE
The chart shown below provides a general overview of the user interface on the VSM user
interface. Please note however that the functions of the buttons vary according to the
operating mode selected by the user. Please consult the next chapters for further details on
how the system reacts to the pressing of such buttons.
BUTTON
Button ID
Main Functions
Status
Go to main menu (“System”)
Teach
Go to “Adjust” status
Set
Confirms selected option
Confirms setting value
Esc
Exit without saving
Back to previous screen
Arrows
Changes selected option
Movement/resizing of the ROI
Changes the parameters
