DATAVS2-VSM INSTRUCTION MANUAL
46
13
13 SPECIFICATIONS
Item
Description
Supply voltage:
24 Vdc ± 10%
Ripple voltage:
2.4 Vpp max.
Current draw:
Max 150 mA @ 24Vdc max
Dimensions:
96 x 96 x 39 mm
Indicators:
8 LEDs + 3.5'' colour LCD monitor
Setup:
DataVS2 GUI
Data retention:
Non volatile FLASH memory
Operating temperature:
-10 °C ... +55 °C
Storage temperature:
-20 °C ... +70 °C
Vibrations:
(EN60068-2-6)
14 mm @ 2 to 10 Hz;
1.5 mm @ 13 to 55 Hz;
2 g @ 70 to 200 Hz; 2 hours on each axis
Shock resistance:
(EN60068-2-27)
11 ms (30 G) 6 shocks on each axis
Housing material:
ABS
Mechanical protection:
IP20 (IP40 when panel mounted)
Connections:
2 x M12 4 poles
Weight:
180 g
