Appendix G – Bar Code Details
242 Class Series 2 Programmer’s Manual
Example:
The following example prints a KMART bar code:
<STX>L
D11<CR>
1W1R0000000150100012345678901234567<CR>
121100000000100Barcode W1R<CR>
E
34 567890 123 4567
Barcode W1R
W1s / W1S: Standard 2 of 5
Standard 2 of 5 is a discrete, self-checking, continuous numeric bar code. All of the
information is contained in the bars. Bars are either wide or narrow, typically in a 3:1
ratio. The space is equal to the width of the narrow bar.
Valid Characters: 0-9
Variable length, minimum one digit
Human Readable: W1S; and, Non-Human Readable: W1s
Example:
The following example prints a Standard 2 of 5 bar code:
<STX>L
D11
1W1S8305001000100123456
E
Barcode W1S
W1t: TCIF Linked 3 of 9 (TLC39)
Valid Characters: All ASCII characters.
Variable Length: Encodes a 25-character alphanumeric number in MicroPDF417 symbol.
Specified Length: Encodes a six-digit sequence in a standard Code 39 followed by a link
flag character in Code 3 of 9.
Syntax (spaces added for readability): a W1 t c d eee ffff gggg hhhhhh ; ii…i
