However, each mode will have the following data in common:
• Mode. Indicated outside of the top left corner of the display. This can show NAV
(navigation), A2A (air to air) or A2G (air to ground).
Mode keys:
o Navigation: [1]
o Air to Air: [2], [4] or [6]
o Air to Ground: [7]
• Radar Range. Outside the top right of the display is the current range setting of the easy
radar.
Radar range keys:
o Zoom in: [=]
o Zoom out: [-]
• True Airspeed (TAS). Outside the lower left of the display is the true airspeed of your
aircraft.
• Radar Altitude. Outside the lower right of the display is the radar altimeter that indicates
your altitude above the ground or water.
• Current Heading. Inside the display at the center top is your current aircraft magnetic
heading.
