COCKPIT INSTRUMENTS
This chapter will instruct you about the Su-27 cockpit instrumentation. For successful piloting, you
must understand the function and position of all cockpit instruments.
Figure 24: Su-27 instrument panel
1. Wing leading edge flap position indicator
2. AOA indicator and Accelerometer
3. Airspeed and Mach indicator
4. Weapons control panel
5. Attitude Direction Indicator (ADI)
6. Horizontal situation indicator (HSI)
7. Vertical Velocity Indicator (VVI)
1
2
3
11
10
9
8
7
6
5
4
12
13
20
19
18
17
16
15
14
