The system provides detection of radar signals at the following angles: Azimuth - +/- 180, and
Elevation Range - +/- 30.
The maximum number of threats on screen: Unlimited.
The threat history display duration time: 8 seconds.
Function modes: All (acquisition) or Lock (the "ОБЗОР/ОТКЛ" switch).
Threats types:
П – airborne radar
З - long-range radar
X - medium-range radar
H - short-range radar
F - early warning radar
C - AWACS
"Relative elevation" lights, "power of emission" gauge lights and "Lock/Launch" lights are only in
regards to the primary threat.
If the time between radar spikes of threat radar is eight or more seconds, the azimuth lights will not
blink.
In the case of an acquisition-type spike, the low frequency audio tone will sound.
If a radar is in lock mode, the "Lock/Launch" indicator will light up, along with a steady, high
frequency audio tone.
If a radar-guided missile launch is detected, the "Lock/Launch" light will flash, along with a high
pitched audio tone.
An ARH missile can be detected by the system after a missile establishes a lock using its own radar
seeker. In this case, the missile will become the primary threat. The cue to recognize an ARH missile
is the rapid increase in signal strength ("power of emission" lamps).
