Figure 60: Lead Computed Opitcal Sight (LCOS) mode
• The aiming crosshair appears when the target range is less than 1200 meters.
• The gun employment range scale indicates target range from 0 to 1200 meters.
• Target range is also displayed on the vertical range scale on the left side of the HUD. The
scale is set for 5 km.
• The remaining ammunition quantity displays the remaining ammunition in quarters, from 4
to 1.
For effective fire, place the aiming crosshair over the target marker and open fire by pressing the
[Space] key.
If the targeting sensors are malfunctioning or disabled, the Gun Funnel mode can be used for aimed
cannon fire.
