Installation – Terminal Description
26
4.1.1 DC SUPPLY, FUEL AND START OUTPUTS, OUTPUTS C, D, E & F
Pin
No
Description Cable Size Notes
1
DC Plant Supply Input
(Negative)
2.5mm²
AWG 13
2
DC Plant Supply Input
(Positive)
2.5 mm²
AWG 13
Supplies the module and DC Outputs A, B, C, D, E & F
3 DC Output A (FUEL)
2.5mm²
AWG 13
Plant Supply Positive from terminal 2.
10A for 10secs, 5A resistive continuous
Fixed as FUEL relay if electronic engine is not configured.
4 DC Output B (START)
2.5mm²
AWG 13
Plant Supply Positive from terminal 2.
10A for 10secs, 5A resistive continuous
Fixed as START relay if electronic engine is not configured.
5 Charge Fail / Excite
2.5mm²
AWG 13
Do not connect to ground (battery negative).
If charge alternator is not fitted, leave this terminal
disconnected.
6 DC Output C
1.0mm²
AWG 18
Plant Supply Positive from terminal 2. 2 Amp rated.
7 DC Output D
1.0mm²
AWG 18
Plant Supply Positive from terminal 2. 2 Amp rated.
8 DC Output E
1.0mm²
AWG 18
Plant Supply Positive from terminal 2. 2 Amp rated.
9 DC Output F
1.0mm²
AWG 18
Plant Supply Positive from terminal 2. 2 Amp rated.
NOTE: Terminals 8 & 9 are not fitted to DSE4510 controller.
NOTE: When the module is configured for operation with an electronic engine, FUEL and
START output requirements may be different. For further details on connection to electronic
engines, refer to DSE Publication: 057-004 Electronic Engines And DSE Wiring
NOTE: For further details of module configuration, refer to DSE Publication: 057-172
DSE45xx Configuration Software Manual.
