Front Panel Configuration
66
7.1 ACCESSING THE FRONT PANEL CONFIGURATION EDITOR
• Press the
(-) and ()buttons together to enter the editor mode.
• Press the
or navigation buttons to cycle through the front panel editor to select the required
page in the configuration tables.
• Press the
(+) to select the next parameter or (-) to select the previous parameter within the
current page.
• When viewing the parameter to be edited, press the
() button, the value begins to flash.
• Press the
(+) or (-) buttons to adjust the value to the required setting.
• Press the
() button the save the current value, the value ceases flashing.
• Press and hold the
() button to save and exit the editor, the configuration icon is
removed from the display.
NOTE: Pressing and holding the (+) or (-) buttons will give auto-repeat
functionality. Values can be changed quickly by holding the buttons for a prolonged period
of time.
NOTE: The editor automatically exits after 5 minutes of inactivity to ensure security.
NOTE: The PIN number is not set by DSE when the module leaves the factory. If the
module has a PIN code set, this has been affected by your generator supplier who should be
contacted if you require the code. If the code has been ‘lost’ or ‘forgotten’, the module must
be returned to the DSE factory to have the module’s code removed. A charge will be made for
this procedure.
NB - This procedure cannot be performed away from the DSE factory.
NOTE: The PIN number is automatically reset when the editor is exited (manually or
automatically) to ensure security.
NOTE: More comprehensive module configuration is possible via PC configuration
software. For further details of module configuration, refer to DSE Publication: 057-172
DSE45xx Configuration Software Manual.
