5 DESCRIPTION OF CONTROLS
NOTE: The following descriptions detail the sequences followed by a module containing
the standard ‘factory configuration’. Always refer to your configuration source for the exact
sequences and timers observed by any particular module in the field.
Control of the module is via push buttons mounted on the front of the module with
Stop/Reset Mode
, Auto Mode and Manual/Start Mode
functions. For normal operation,
these are the only controls which need to be operated. Details of their operation are provided later in
this document.
CAUTION: The module may instruct an engine start event due to external influences.
Therefore, it is possible for the engine to start at any time without warning. Prior to
performing any maintenance on the system, it is recommended that steps are taken to remove
the battery and isolate supplies.
Manual / Start
Mode
Auto Mode
Stop / Reset
Mode
Menu
Navigation
Module
Display
Stop / Reset
Mode LED.
Will flash
upon
Electrical Trip
and Shutdown
Manual / Start
Mode LED.
Will flash
upon Waiting
in Manual
Mode
