Viewing The Instrument Pages
41
5.2.2 ACTIVE CONFIGURATION
An icon is displayed in the Active Config section to indicate the active configuration within the
currently selected within the controller.
Icon Details
Appears when the main configuration is selected.
Appears when the alternative configuration is selected.
5.2.3 FRONT PANEL EDITOR (FPE) / AUTO RUN ICON
NOTE: For further details about the Front Panel Editor, see the section entitled ‘Front
Panel Editor’ elsewhere in this manual.
When running in Auto Mode and on the Home (
/
) page, an icon is displayed in the FPE / Auto
Run section to indicate the source of the auto start signal.
Icon Auto Run Reason
Appears when a remote start input is active
Appears when a low battery run is active
Mains failure
Appears when a scheduled run is active
5.2.4 MODE ICON
An icon is displayed in the Mode Icon section to indicate the mode the controller is currently in.
Icon Details
Appears when the engine is at rest and the unit is in stop mode.
Appears when the engine is at rest and the unit is in auto mode.
Appears when the engine is at rest and the unit is waiting for a manual start.
Appears when a timer is active, for example cranking time, crank rest etc.
Appears when the engine is running, and all timers have expired, either on or off load.
The animation speed is reduced when running in idle mode.
Appears when the unit is in the front panel editor.
Appears when a USB connection is made to the controller.
Appears if either the configuration file or engine file becomes corrupted.
