DEEP SEA ELECTRONICS DSE4520 User Manual

Front Panel Configuration
68
7.2.3 INPUT SETTINGS
Configuration Parameters – Inputs (Page 3)
301 Digital Input A Source 0 (Input Source)
302 Digital Input A Polarity 0 (Polarity)
303 Digital Input A Action (If Source = User Config) 0 (Action)
304 Digital Input A Arming (If Source = User Config) 0 (Arming)
305 Digital Input A Activation Delay (If Source = User Config) 0 s
306 Digital Input B Source 0 (Input Source)
307 Digital Input B Polarity 0 (Polarity)
308 Digital Input B Action (If Source = User Config) 0 (Action)
309 Digital Input B Arming (If Source = User Config) 0 (Arming)
310 Digital Input B Activation Delay (If Source = User Config) 0 s
311 Digital Input C Source 0 (Input Source)
312 Digital Input C Polarity 0 (Polarity)
313 Digital Input C Action (If Source = User Config) 0 (Action)
314 Digital Input C Arming (If Source = User Config) 0 (Arming)
315 Digital Input C Activation Delay (If Source = User Config) 0 s
316 Digital Input D Source 0 (Input Source)
317 Digital Input D Polarity 0 (Polarity)
318 Digital Input D Action (If Source = User Config) 0 (Action)
319 Digital Input D Arming (If Source = User Config) 0 (Arming)
320 Digital Input D Activation Delay (If Source = User Config) 0 s
321-330 RESERVED
331 Analogue Input A (Set As Digital) Source 0 (Input Source)
332 Analogue Input A (Set As Digital) Polarity 0 (Polarity)
333 Analogue Input A (Set As Digital) Action (If Source = User Config) 0 (Action)
334 Analogue Input A (Set As Digital) Arming (If Source = User Config) 0 (Arming)
335
Analogue Input A (Set As Digital) Activation Delay (If Source = User
Config)
0 s
336 Analogue Input B (Set As Digital) Source 0 (Input Source)
337 Analogue Input B (Set As Digital) Polarity 0 (Polarity)
338 Analogue Input B (Set As Digital) Action (If Source = User Config) 0 (Action)
339 Analogue Input B (Set As Digital) Arming (If Source = User Config) 0 (Arming)
340
Analogue Input B (Set As Digital) Activation Delay (If Source = User
Config)
0 s
341 Analogue Input C (Set As Digital) Source 0 (Input Source)
342 Analogue Input C (Set As Digital) Polarity 0 (Polarity)
343 Analogue Input C (Set As Digital) Action (If Source = User Config) 0 (Action)
344 Analogue Input C (Set As Digital) Arming (If Source = User Config) 0 (Arming)
345
Analogue Input C (Set As Digital) Activation Delay (If Source = User
Config)
0 s
