7.2.9 ANALOGUE INPUTS SETTINGS
Configuration Parameters – Analogue Input Settings (Page 9)
901 Analogue Input A Senor Type 0 (Sensor Type)
902 Analogue Input A Sensor Selection 0 (Pressure Sensor List)
903 Low Oil Pressure Enable On (1), Off (0)
904 Low Oil Pressure Trip 0 Bar
905 Oil Pressure Sender Open Circuit On (1), Off (0)
906 Analogue Input B Senor Type 0 (Sensor Type)
907 Analogue Input B Sensor Selection 0 (Temperature Sensor List)
908 High Engine Temperature Trip 0.00 °C
909 Temperature Sender Open Circuit On (1), Off (0)
910 Analogue Input C Sensor Usage Flexible Sensor (1), Fuel Level Sensor (0)
911 Analogue Input C Senor Type 0 (Sensor Type)
912 Analogue Input C Sensor Selection
0 (Pressure / Temperature / Percentage
Sensor List)
913 Flexible Sensor C Arming 0 (Arming)
914 Flexible Sensor C Low Alarm Action 0 (Action)
915 Flexible Sensor C Low Alarm Trip 0 % / Bar / °C
916 RESERVED
917 Flexible Sensor C Low Pre-Alarm Enable On (1), Off (0)
918 Flexible Sensor C Low Pre-Alarm Trip 0 % / Bar / °C
919 Flexible Sensor C Low Pre-Alarm Return 0 % / Bar / °C
920 RESERVED
921 Flexible Sensor C High Pre-Alarm Enable On (1), Off (0)
922 Flexible Sensor C High Pre-Alarm Return 0 % / Bar / °C
923 Flexible Sensor C High Pre-Alarm Trip 0 % / Bar / °C
924-925 RESERVED
926 Flexible Sensor C High Alarm Action 0 (Action)
927 Flexible Sensor C High Alarm Trip 0 % / Bar / °C
928-929 RESERVED
930 Fuel Sensor C Low Shutdown Enable On (1), Off (0)
931 Fuel Sensor C Low Shutdown Trip 0 %
932 Fuel Sensor C Low Shutdown Delay 0 s
933 Fuel Sensor C Low Pre-Alarm Enable On (1), Off (0)
934 Fuel Sensor C Low Pre-Alarm Trip 0 %
935 Fuel Sensor C Low Pre-Alarm Return 0 %
936 Fuel Sensor C Low Pre-Alarm Delay 0 s
937 Fuel Sensor C High Pre-Alarm Enable On (1), Off (0)
938 Fuel Sensor C High Pre-Alarm Return 0 %
939 Fuel Sensor C High Pre-Alarm Trip 0 %
940 Fuel Sensor C High Pre Alarm Delay 0 s
941 RESERVED
942 Fuel Sensor C High Alarm Action 0 (Action)
943 Fuel Sensor C High Alarm Trip 0 %
944 Fuel Sensor C High Alarm Delay 0 s
