Front Panel Configuration
76
x Functionality in all DSE4510 & DSE4520 variants
x Functionality in all DSE4520 variants
x Functionality in DSE4510 & DSE4520 current sensing variants only
x Functionality in DSE4510 & DSE4520 RT & RTH variants only
Configuration Parameters – Alternate Configuration (Page 20)
2024 CT Primary 0 A
2025 Full Load Rating 0 A
2026 Immediate Over Current On (1), Off (0)
2027 Delayed Over Current Alarm On (1), Off (0)
2028 Delayed Over Current Alarm Action 0 (Action)
2029 Over Current Delay 00:00:00
2030 Over Current Trip 0 %
2031 Generator kW Rating 0 kW
2032 Overload Protection Enable On (1), Off (0)
2033 Overload Protection Action 0 (Action)
2034 Overload Protection Trip 0 %
2035 Overload Protection Trip Delay 0 s
2036 AC System 0 (AC system)
2037 Mains Failure Detection On (1), Off (0)
2038 Immediate Mains Dropout On (1), Off (0)
2039 Mains Under Voltage Enable On (1), Off (0)
2040 Mains Under Voltage Trip 0 V
2041 Mains Under Voltage Return 0 V
2042 Mains Over Voltage Enable On (1), Off (0)
2043 Mains Over Voltage Return 0 V
2044 Mains Over Voltage Trip 0 V
2045 Mains Under Frequency Enable On (1), Off (0)
2046 Mains Under Frequency Trip 0.0 Hz
2047 Mains Under Frequency Return 0.0 Hz
2048 Mains Over Frequency Enable On (1), Off (0)
2049 Mains Over Frequency Return 0.0 Hz
2050 Mains Over Frequency Trip 0.0 Hz
2051 Under Speed Shutdown Enable On (1), Off (0)
2052 Under Speed Shutdown Trip 0 RPM
2053 Over Speed Shutdown Trip 0 RPM
