Edit Configuration -Inputs
29
Transfer to Mains/ Open
Generator
IEEE 37.2 - 52 AC circuit breaker
This input is used to transfer the load to the mains supply (AMF
module) when running in MANUAL MODE or provide the ‘Open
Generator’ signal in a non AMF Module.)
Transfer to generator/Open
Mains
IEEE 37.2 - 52 AC circuit breaker
This input is used to transfer the load to the generator when running in
MANUAL MODE
On the DSE 7420 module only: Once synchronised the genset and
bus/mains will parallel. The second press of the button (or expiry of the
parallel run timer) will then cause the genset to take full load and open
the mains contactor.
