Edit Configuration - Outputs
33
Output source
Activates… Is not active….
Calling For Scheduled Run
Active during a
scheduled run
request from the i
nbuilt scheduler.
CAN ECU Data Fail
Becomes active when no CAN data
is received from the ECU after the
safety delay timer has expired
Inactive when:
• CAN data is being received
• The set is at rest
• During the starting sequence before
the safety delay timer has expired
CAN ECU Power
Used to switch an external relay to power the CAN ECU. Exact timing of this
output is dependent upon the type of the engine ECU
CAN ECU Shutdown
The engine ECU has indicated that a
Shutdown alarm is present.
Inactive when no Shutdown alarm from
the ECU is present
CAN ECU Stop
Active when the DSE controller is requesting that the CAN ECU stops the
engine.
CAN ECU Warning
The engine ECU has indicated that a
Warning alarm is present.
Inactive when no Warning alarm from
the ECU is present
Charge Alternator Failure
(Shutdown or warning)
Indicates that there is a charging
fault with the auxiliary charging
alternator
• When the set is at rest
• During the starting sequence before
the safety delay timer has expired
Close Gen Output
IEEE 37.2 – 52 ac circuit breaker
Used to control the load switching
device. Whenever the 8600 module
selects the generator to be on load
this control source will be active.
Inactive whenever the generator is not
required to be on load
Close Gen Output Pulse
IEEE 37.2 – 52 ac circuit breaker
Used to control the load switching device. Whenever the DSE7400 module
selects the generator to be on load this control source will be active for the
duration of the Breaker Close Pulse timer, after which it will become inactive
again.
Close Mains Output
IEEE 37.2 – 52 ac circuit breaker
Used to control the load switching device.
Whenever the
DSE7400 module selects
the mains to be on load this control source
will be active.
The output is inactive whenever
the mains is not required to be on
load
Close Mains Output Pulse
IEEE 37.2 – 52 ac circuit breaker
Used to control the load switching device. Whenever the DSE7400 module
selects the mains to be on load this control source will be active for the duration
of the Breaker Close Pulse timer, after which it will become inactive again.
Closed to mains state
Used to be active when the status of the mains breaker is closed.
Combined Mains Failure
Active when the mains supply is out of limits OR the input for Auxiliary Mains
Failure is active
Combined Maintenance alarm
Indicates that one of the maintenance alarms is active
Combined Remote Start Output
Indicates that a remote start input is active.
Combined Under and Over frequency
shutdown
IEEE 37.2 - 81 frequency relay
Active when the generator is shutdown due to either under OR over frequency
Combined Under and Over frequency
warning
IEEE 37.2 - 81 frequency relay
Active when the generator alarm for either under OR over frequency is active
